STANDARD 3.0 / MASTER 3.0 USERS GUIDE



Thank you for choosing the BbTALKIN’ Bluetooth communication system. This instruction manual will help you operate this system. First, read this manual carefully and familiarise yourself with functionalities before use. You can also read more about pairing on our Pairing support page.



www.bb-talkin.eu



Specs


  •
  • Intercall talk time: 14 hr
  •
  • Charge time: 2.5 hr
  •
  • Weight: 65 g
  •
  • Range: 1000 m
  •
  • Water-proof: IPX7 (*must be in the waterproof case)
  •


Charge



AC adaptor: 5V +5% 500mA



Charging cable: USB Type-C


  •
  • Red = Charging
  •
  • Blue = Fully charged
  •


Battery status:
  LED indicator after power ON
  Blue = 100%–60%
  Purple = 60%–40%
  Red = 40%–0%



Tone Sound


  •
  • bbtalkin intercom = 100%–60%
  •
  • battery mid = 60%–40%
  •
  • battery low = 40%–0%
  •


Update


  1.
  2. Install update tool and Firmware from our website.
  3.
  4. Plug USB Type-C into PC or pair with mobile phone to start.
  5.
  6. For more detail: bb-talkin.eu/softwareupdates
  7.


⚠️ WARNING


  •
  • DO NOT modify or disassemble the device.
  •
  • Make sure device is completely dry before charging.
  •
  • Do not use in airplane or near medical equipment such as pacemakers.
  •
  • Do not expose to extreme temperature or humidity.
  •
  • If damaged, stop using immediately.
  •


Bb3.0 STANDARD



Pairing with another Standard


  1.
  2. Power on: Press and hold the POWER until LED is on.
  3.
  4. Pairing mode: Press and hold both devices’ INTERCALL until red LED is quickly flashing.
  5.
  6. Begin pairing: Click either one of device’s INTERCALL once quickly — devices are finding each other.
  7.
  8. Pairing successful: When paired, you will hear confirmation on your headset.
  9.


⚠️ NOTICE: Once paired, your devices memorize the pairing. Do not go through pairing process again. For everyday use, quickly click either device’s INTERCALL button after powering on.



Connect/Disconnect



Quickly press either device’s INTERCALL button once.



Mute



Click MUTE once to turn the microphone on/off.



Pairing with your mobile phone



(STANDARD device only. MASTER cannot pair phone)


  1.
  2. Enable mobile phone’s Bluetooth search mode.
  3.
  4. While unit is OFF, press and hold POWER until LED blue & red flashes.
  5.
  6. Select “bb30” on phone screen.
  7.
  8. Once LED slowly flashes blue, pairing is complete.
  9.


Hands Free


  •
  • Pick up / Hang up call: Click POWER once.
  •
  • Decline call / Redial: Click POWER twice quickly.
  •


Music Play


  •
  • Play / Pause music: Click POWER once.
  •
  • Forward / Backward: Press and hold 2 sec. Vol+ for forward, Vol− for backward.
  •


Reset (back to default)



While OFF, press and hold (3 sec) the POWER and VOL+ at the same time until purple LED flashes.



⚠️ NOTICE: When pairing or re-pairing any STANDARD or MASTER devices, they must first be reset before pairing.



Bb3.0 MASTER



You need a MASTER device to communicate with more than two people.



3-WAY COMMUNICATION: STANDARD + STANDARD + MASTER


  1.
  2. Power on: Press and hold MASTER CH2 and STANDARD POWER until LED is on.
  3.
  4. Pairing mode:
    •
    • MASTER: Press and hold CH1 until red LED flashes.
    •
    • 1st STANDARD: Press and hold INTERCALL until red LED flashes.
    •

  5.
  6. Click MASTER CH1 once — devices will pair.
  7.


⚠️ Do not click STANDARD INTERCALL.



Pairing successful: You will hear “connected.”



Pairing 2nd STANDARD DEVICE: Repeat process, pairing to MASTER CH3.



⚠️ NOTICE: Pairing to MASTER CH2 is a different process (see below).



4-WAY COMMUNICATION: STANDARD + STANDARD + STANDARD + MASTER


  1.
  2. Pairing mode:
    •
    • MASTER: While OFF, press and hold (5 sec) MASTER CH2 until LED flashes red.
    •
    • 3rd STANDARD: Press and hold INTERCALL until red LED flashes.
    •

  3.
  4. Click MASTER CH2 once to complete pairing.
  5.


⚠️ Do not click STANDARD INTERCALL.



Pairing successful: You will hear “connected.”



⚠️ NOTICE: Once paired, devices remember each other. Label your Standards by channel for easy reconnection.



Connect/Disconnect



After powering on, press the MASTER CH button once for the STANDARD you wish to connect. Standards can also connect via INTERCALL.



⚠️ NOTICE: Do not press CH1, 2, and 3 simultaneously. After CH2 connects, you can call out CH2 or CH3.



Mute



Press Vol+ and Vol− once at the same time to mute/unmute the microphone.



Reset (back to default)



While OFF, press and hold (3 sec) CH2 and Vol+ simultaneously until purple LED flashes.



⚠️ NOTICE:


  •
  • MASTER cannot pair with mobile phone (except update mode).
  •
  • MASTER cannot pair with another MASTER.
  •
  • MASTER and STANDARD cannot pair to ADVANCE units.
  •


LIMITED WARRANTY



This limited warranty covers defects in materials and workmanship for twelve (12) months for main device only.



The warranty does not cover damage from misuse, modification, corrosion, moisture, accidents, or non-BbTalkin parts. Only original purchasers are covered; warranty is not transferable.



How to Obtain a Remedy



Contact your authorized BbTalkin reseller or nearest BbTalkin office. Visit www.bb-talkin.eu for a list of resellers.



Provide a dated proof of purchase. For returns, obtain a return authorization number from BbTalkin before shipping.



Limitation on Liability



The maximum liability of BbTalkin under this limited warranty shall not exceed the actual purchase price paid. BbTalkin is not responsible for direct, special, incidental, or consequential damages resulting from any breach of warranty or condition.



Some regions do not allow such limitations, so these may not apply to you.



BbTalkin Europe — www.bb-talkin.eu
